Place of Origin:
China
Brand Name:
CHENGUANG FSP
Certification:
FDA
Model Number:
DHS-140
Contact Us
High Transparency Silicone Rubber
High Transparency Silicone Rubber 600% Elongation for Resin Embedding Applications
DESCRIPTION
High transparency silicone rubber is a type of synthetic rubber that has exceptional clarity and transparency, making it ideal for applications that require a clear view of components or products. It has a 8Mpa tensile strength, indicating that it can withstand a force of 8 MegaPascals before breaking. This strength makes it a durable and reliable material for various applications. The 600% elongation at breakage shows that it can stretch up to 600% of its original length before breaking, demonstrating its flexibility and ability to withstand deformation. The 22 Dielectric Strength indicates its ability to resist electrically-induced breakdown, making it a suitable material for electrical and electronic components. Overall, High transparency silicone rubber is a versatile material with unique properties that offer superior performance and reliability in a wide range of applications.
SPECIFICATION
| Model |
DHS-130
|
DHS-140 | |
| Appearance |
Translucent,no obvious extraneous matter |
||
| Density (g/cm3) |
1.07±0.04 |
1.13±0.04 |
|
| Hardness (Shore A Points) |
30±2
|
40±2 |
|
| Tensile Strength (MPa≥) |
8.0
|
8.0 |
|
| Elongation at Breakage (%≥) |
700
|
600 |
|
| Tension Set (% ≤) |
8 |
8 | |
| Tear Strength (kN/m ≥) |
15
|
20 | |
|
Volume Resistivity (Ω.cm) |
1.0X1016 |
||
|
Dielectric Strength (kv/mm≧) |
22 |
||
|
Linear Shrinkage Rate after the first vulcanization (%) |
3.1-3.7 |
3.0-3.6 |
|
Physical and Mechanical Properties are based on the first vulcanization data,Electrical Properties are drawn from the second vulcanization data.
The first vulcanization condition for test piece: 175℃×5min；The second vulcanization condition for test piece: 200℃×2h
Vulcanizator: Liquid DMDBH, quantity added 0.65%
THE POTENCIAL OF SILICONE
High Transparency Silicone Rubber is an advanced material with excellent optical properties. It is used in a wide range of applications, including medical devices, optical components, and electronics. The future of High Transparency Silicone Rubber is promising, as it can be used in various industries. The demand for this material is expected to grow in the coming years due to its unique properties, such as high transparency, durability, and biocompatibility. With the increasing demand for high-performance materials, High Transparency Silicone Rubber is likely to become a popular choice for designers and manufacturers looking for a versatile and reliable material. Furthermore, new innovations in the field of High Transparency Silicone Rubber are expected to bring about even more exciting applications for this material in the future.
APPLICATIONS
Silicon metal is also a crucial component in various products and applications:
